Product Overview
The 12V LED Indicator Lights (Model: FL1M-12FW-1) by FILN are professional-grade signaling solutions engineered for extreme durability. Featuring a 12mm mounting hole and IP67 waterproof rating, these metal flat-head lights are certified by ISO9001, CE, VDE, RoHS, SGS, UL. These indicators excel in industrial control panels, CNC machines, and marine systems. With a robust stainless steel or black aluminum housing and pre-wired 15cm leads, they offer superior vibration resistance and long-term reliability compared to standard plastic alternatives. Available in Red, Green, Yellow, Blue, and White, they support global voltage requirements from 12V to 220V.
Quick Specifications
| Mounting Hole | 12mm (0.47 inches) |
|---|---|
| Voltage | 12V-24V / 110V-220V (Customizable) |
| LED Color | Red, Green, Yellow, Blue, White |
| Waterproof Rating | IP65 / IP67 |
| Wiring Type | Wire Lead Type (15cm length) |
| Lifespan | 50,000 Hours |
Rated Working Parameters
| Rated Voltage | 12V DC (Supports Customized AC/DC) |
|---|---|
| Frequency (AC) | 50～60Hz |
| Rated Current | ≤20mA |
Component Materials
| Housing | Nickel-plated Brass / Black Aluminum |
|---|---|
| Lens | Polycarbonate (PC) |
| Seal Ring | Silicone (O-ring included) |
| Wire Material | UL1007 22AWG Copper Wire |
General Characteristics
| Operating Temperature | -40℃ ～ 80℃ |
|---|---|
| Relative Humidity | ≤85% at +40℃ |
| Ambient Temperature | 5~35℃ |
| Air Pressure | 86~106Kpa |
Electric Property
| Property | Test Condition | Requirement |
|---|---|---|
| Insulation Resistance | DC500V for 1 minute | ≥100MΩ |
| Dielectric Strength | 1500VAC / 5mA / 60s | No breakdown/flashover |
Resistant Performance
| High Temperature Resistance | 80℃ for 96h |
|---|---|
| Low Temperature Resistance | -40℃ for 96h |
| Moisture Resistance | 40℃, 90-95%RH for 96h |
Key Features
- LED High Brightness: Crystal clear visibility even in high-ambient light environments.
- Long Lifespan: Rated for over 50,000 hours of continuous operation.
- IP67 Waterproof: Full protection against dust and water immersion.
- Flat Head Design: Aesthetic "flush" look that is easy to clean and hard to snag.
- Easy Installation: Pre-wired 15cm leads eliminate the need for difficult soldering in tight spaces.
Applications
- Industrial Control Panels & Automation Equipment
- CNC Machinery and Heavy Tooling
- Marine Dashboard Systems & Yachts
- Medical Testing and Diagnostic Devices
- New Energy Charging Stations & EV Infrastructure
- Electrical Distribution Cabinets
Installation Guide
- Drill a 12mm diameter hole in your mounting panel.
- Insert the LED indicator light from the front of the panel.
- Slide the silicone O-ring onto the threaded body from the back.
- Secure the unit by tightening the M12 hex nut provided.
- Connect the 15cm wire leads to your 12V power source (Polarity independent for AC/DC models).
What Is a 12V LED Indicator Light?
A 12V LED Indicator Light is a critical signaling component used in industrial and consumer electronics to provide visual status feedback. Unlike traditional bulbs, these LED versions consume minimal power and generate almost no heat. In industrial settings, they serve as "pilot lights" to indicate machine power, fault states, or operational cycles. The flat-head design is particularly advantageous as it sits flush against the panel, reducing the risk of accidental damage or interference with other controls.
FILN Factory Direct Supply
- ✓ Customization: Voltage, Wire Length, and Connectors tailored to your project.
- ✓ Stock: Silver and Black housing finishes available for immediate dispatch.
- ✓ Shipping: Fast Global Logistics for B2B procurement.
FILN Official Website: www.filn.com
Contact Us: inquiry@cnylin.com.cn
Frequently Asked Questions
1. Can I use these 12V LEDs on a 24V system?
While specifically rated for 12V, we offer custom 12-24V wide-voltage versions upon request.
2. What is the advantage of wire leads over pin terminals?
Pre-wired leads (15cm) save time during assembly and provide a more secure connection in high-vibration environments like marine or CNC applications.
3. Are these lights suitable for outdoor marine use?
Yes, the IP67 rating and stainless steel housing options make them highly resistant to saltwater and rain.
4. Does the package include mounting hardware?
Every FILN 12mm light comes with a silicone O-ring and a smooth-threaded M12 nut.
5. Can I get a black housing instead of silver?
Yes, we supply both silver nickel-plated brass and black anodized aluminum housings.
6. Is it possible to customize the wire length?
Absolutely. As a factory, FILN can customize wire lengths (e.g., 30cm, 50cm) and add specific connectors.
7. What colors are available for the 12mm indicator?
Standard colors include Red, Green, Yellow, Blue, and White.
8. Do these indicators work on AC or DC?
They are available in both DC only and universal AC/DC configurations.
9. Are these certified for medical equipment?
Yes, our lights meet CE and RoHS standards, making them suitable for medical diagnostic devices.
10. How do I install the flat-head version?
Insert through a 12mm hole and tighten the nut from behind; the flat head will sit nearly flush with the panel surface.
Dear Valued Customers,
At FILN, we specialize in delivering precision-engineered indicator lights, push button switches, and rocker switches tailored to your unique requirements. While our products default to standard voltage ranges (12-24V and 110-220V), we understand that specialized applications demand flexibility.
Need a Custom Voltage Solution? Simply inform us of your desired voltage specifications (e.g., 5V, 48V, or non-standard ranges), and our engineering team will craft a solution within 10-15 business days.
Why Choose FILN for Custom Manufacturing?
✅ Expertise You Can Trust: Over 20 years of experience in industrial-grade electronic component production.
✅ End-to-End Customization: From voltage adjustments to bespoke designs (shape, color, IP rating), we adapt to your needs.
✅ Quality Guaranteed: All custom orders undergo rigorous testing to meet CE/RoHS/IP65 standards.
✅ Scalable Support: Whether prototyping or bulk orders, we ensure seamless delivery.
How It Works
Consultation: Share your technical requirements via email or our contact form.
Design & Approval: Receive 3D models or samples for confirmation.
Production & QC: Precision manufacturing with real-time updates.
Global Shipping: Trackable logistics to your doorstep.
Contact Us Today
Email: inquiry@cnylin.com.cn
A
good
U
I had purchased an indicator lamp from a different online market place only to be disappointed in its quality, so it was never installed. This lamp is much better and works as I envisioned. The wire leads are heavy enough so that they’re easy to work with, more than just a couple of strands of wire. The lamp is bright enough without being overpowering. It’s installed in an electric heat in floor boiler that is powered by a feed that can be powered off during high electric demand. The indicator allows me to see when power is present without having to walk into the utility room.
G
We purchased both the green and yellow 12mm lights. The green flat model is highly brilliant, but the yellow LED bead seems a bit soft under high-intensity overhead factory lighting.
Thank you for your valuable observation! Due to the baseline physics of LED semiconductor wafers, yellow light has lower natural lumen output than green. We can customize high-intensity, high-lumen yellow LED chips for your next factory run. Please contact our support desk.
V
Not very bright, but otherwise nice build quality.
S
The black shell flat indicator mounts easily and the pigtail tail is great. The blue and green options look incredibly vivid, but the yellow model isn't bright enough under direct afternoon sunlight.
Hello! For outdoor control grids exposed to sunlight, standard yellow chips can look washed out. We offer customized high-output LED chips engineered specifically for sunny environments. We will reach out to provide you with sample modules for your setup.
T
Locks tightly onto metal plates with zero play. The non-polar capability makes layout wiring incredibly fast.
B
These lights were exactly as described and work perfectly 👍
H
Instalado en cuadros de automatización con espacio reducido. La longitud y el cable directo ayudan mucho. Excelente soporte.
N
Der Kabelanschluss spart Lötzeit. Die Produktinformationen auf der Website sind detailliert und präzise. Sehr zu empfehlen.
S
I installed this 110V light to my electric water heater element so I could see if the heating element was working and when it was at temp. Every RV with a 110V water heater should have one of these. For the RV readers, it took my five gallon Atwood water heater to reach temp in 55 minutes from cold. I've always wondered....
A
Just connect the wire leads to your circuit without checking poles. Perfect for fast-paced assembly lines. Excellent metal finish.
P
The anodized outer coating resists scratching during tightening. Direct wire tail configuration is clean. Highly luminous.
E
Solid non-polar LED beads, clean thread pitches, and clear specifications provided by FILN. My only complaint is that shipping was slow. Be sure to order in advance or pay for premium express air.
Thank you for the compliment on our thread machining and complete specifications map. We are actively expanding regional stocking partnerships to drastically reduce delivery timelines for all overseas manufacturing accounts.
M
Das Modell 12V LED Indicator Lights passt perfekt in unsere Schalttafeln. Die flache Bauform sieht sehr edel aus und das Gewinde läuft flüssig. FILN bietet schnellen Support.
O
We required custom voltage adjustments for a specific medical tool layout and the engineering department confirmed specifications rapidly. Reliable and robust metal bodies.
J
Trou de montage de 12mm précis. La finition argentée est superbe sur nos consoles. Pas de polarité requise, câblage facile.
C
The 12V LED Indicator Lights function beautifully on our test panel, and the flat head look is premium. However, standard ocean freight took forever to reach our US depot.
Dear customer, thank you for praising our flat head 12mm indicator light. We sincerely apologize for the shipping delay caused by current congestion at the maritime ports. We highly recommend using our expedited air options (DHL/FedEx/UPS) for urgent production schedules.
P
Boîtier noir élégant, filetage parfait. Les informations techniques sont claires sur le site. Idéal pour l'automatisation.
S
Il montaggio da 12mm è preciso e la testa piatta si allinea perfettamente al pannello. Filettatura liscia e cablaggio rapido.
T
Clean silver finish that blends into aluminum frames. Bipolar configuration means seamless AC/DC integration. Fully certified and packed securely. A top tier factory supplier.
T
All CE and safety compliance files are available. Product looks high-end with exceptionally clean thread profiles.
C
No issues mounting on thick steel plates. Threads are deeply cut and smooth. Professional communication from factory.
P
FILN technical support was exceptionally fast to reply and provided clear certification data sheets. Regrettably, the shipping package sat at the clearing facility for 12 days. The pre-wired lamps are top quality though.
Thank you for verifying our component quality and technical documentation. Custom clearance schedules can sometimes vary unpredictably. We are coordinating with international custom brokers to optimize documentation speed and prevent future holding delays.
J
Installed these 12V metal lights on water irrigation boxes. The flat design keeps it clean. Wires are durable and well-insulated.
H
12V LED Indicator Lights 모델을 장비 제어반에 설치했습니다. 평두형이라 표면이 깔끔하게 떨어지고 무극성이라 배선이 정말 쉽습니다. FILN 공장의 기술 답변이 매우 빠릅니다.
B
The 12mm metal indicator light operates perfectly and the non-polar wiring made installation simple. Sadly, the economy delivery took almost 20 days. Please provide faster express alternatives on the checkout page.
We appreciate your constructive review. We do support multiple rapid air express lines to match urgent development timelines. We will make sure our sales team explicitly highlights these accelerated shipping channels during your next sourcing request.
J
No polarity concerns means zero assembly errors for our technicians. Bright light distribution and clean metal casing.
I
The flat head minimizes dust capture on excavators. Wires are ruggedly potted into the rear tail assembly.
S
THIS 110V LED REPLACES ONE THAT IS RIGHT UNDER MY KITCHEN SINK AND LIGHTS UP WHEN THE WATER PUMP OUT IN THE WELL RUNS. IT LETS ME KNOW IF I DEVELOP A WATER LEAK. INSTALLATION WAS EASY AND BRIGHTNESS OF THE LED BULB IS VERY GOOD!
